Intermec CN2G User Manual
Page 28
Chapter 1 — Using the CN2G Handheld Computer
16
CN2G Handheld Computer User’s Manual
Use Intermec Settings to enable and disable symbologies.
For help understanding how to use Intermec Settings, see
“Configuring the CN2G Locally With Intermec Settings” on
page 24.
To scan a bar code label with the CN2G
1
Press the Power key to turn on the CN2G.
2
Point the scanner window at the bar code label and hold the
computer at a slight angle 15 to 25 cm (6 to 10 in) from the
label.
CN2
Scan
button
Good
Read light
Side Scan
buttons
F2
F1
SCAN
ENTER
3
Press the Scan button on the keypad or one of the Side Scan
buttons on the CN2G and center the red beam so that it falls
across all bars in the bar code label.
Use this test bar code:
Code 39 Test Bar Code
*123456*
*123456*
When the CN2G successfully reads a bar code label, you hear
a high beep and the green Good Read light turns on briefly.
4
Release the Scan button or Side Scan button.
