FRU Name AIX
Location Code Physical
Location Code Physical
Connection Logical
Identification
SCSI Backplane
C
When
connected to
SCSI Port 1
(P2/Z1) 10-60-00-15, 0 P2-Z1-B2 Primary SCSI
Bus ID 15
SCSI Backplane
C
When
connected to
SCSI Port 2
(P2/Z2) 30-58-00-15, 0 P2-Z2-B2 Secondary SCSI
Bus ID 15
DASD in Bays
C1 through C6
When
connected to
SCSI Port 1
(P2/Z1) 10-60-00-G, 0
Where G
identifies
Primary SCSI
Bus ID 8
through 13 P2-Z1-B2.1
through B2.6 Primary SCSI
Bus ID 8
through 13
DASD in Bays
C1 through C6
When
connected to
SCSI Port 2
(P2/Z2) 30-58-00-G, 0
Where G
identifies
Secondary SCSI
Bus ID 8
through 13 P2-Z2-B2.1
through B2.6 Secondary SCSI
Bus ID 8
through 13
SCSI Backplane
D
When
connected to
SCSI Port 2
(P2/Z2) 30-58-00-15, 0 P2-Z2-B2 Secondary SCSI
Bus ID 15
SCSI Backplane
D
When
connected to
PCI adapter in
slot P2-In AB-CD-00-15, 0
Where AB-CD
identifies the
adapter's slot P2-In-Z1-B2 Bus ID 15
DASD in Bays
D1 through D6
When
connected to
SCSI Port 2
(P2/Z2) 30-58-00-G, 0
Where G
identifies
Secondary SCSI
Bus ID 8
through 13 P2-Z2-B2.1
through B2.6 Backplane
connector J6
through J11
Slots A through
F Secondary SCSI
Bus ID 8
through 13
6-18 IBM RS/6000 7025 F50 Series User's Guide
