FRU Name AIX
Location Code Physical
Location Code Physical
Connection Logical
Identification
Memory Card 2 00-00 P1-M2 Processor
Connector J13
Memory Card 2
DIMMS 1 thru
16 00-00 P1-M2.1
through
P1-M2.16 Memory Card
Sockets
J1,J2,J3,J4,
J5,J6,J7,J8
J9,J10,J11,J12,
J13,J14,J15,J16 Extents:
8L,8H,10L,10H,
12L,12H,14L,14H
9L,9H,11L,11H,
13L,13H,15L,15H
I/O Planar 00-00 P2
Integrated Devices
Diskette Drive 01-D1-00-00 P2-D1 I/O Planar
Connector J13 Base Address
0x0310
Keyboard 01-K1-00-00 P2-K1 I/O Planar
Connector J23 Base Address
0x0060
Mouse 01-K1-01-00 P2-O1 I/O Planar
Connector J27 0x0060
Diskette Port 01-D1 P2/D1 I/O Planar
Connector J13 0x03f0
Keyboard Port 01-K1-00 P2/K1 I/O Planar
Connector J23 0x0060
Mouse Port 01-K1-01 P2/O1 I/O Planar
Connector J27 0x0060
Serial Port 1 01-S1 P2/S1 I/O Planar
Connector J41 0x0318
Serial Port 2 01-S2 P2/S2 I/O Planar
Connector J41 0x0218
Serial Port 3 01-S3 P2/S3 I/O Planar
Connector J50 0x0898
Parallel Port 01-R1 P2/R1 I/O Planar
Connector J47 0x0378
Ethernet Port 10-80 P2/E1 I/O Planar
Connector
J18(TH) or
J21(TP) Host Bridge
ID00, Device 06
SCSI Port 1 10-60 P2/Z1 I/O Planar
Connector J25 Host Bridge
ID00, Device 04
SCSI Port 2 30-58 P2/Z2 I/O Planar
Connector J11
and J30 Host Bridge
ID02, Device 06
Pluggable Adapters
6-16 IBM RS/6000 7025 F50 Series User's Guide
