AIMB-744 User’s Manual 42
The Choice : "S1(POS)", and "S3(STR)". While selecting "S3(STR)", the
"Run VGABIOS if S3 Resume" and "Resume on USB from S3" will be
active for selection.
3.7.3 Power Management
This category allows you to select the type (or degree) of power saving
and is directly related to the following modes:
1. HDD Power Down
2. Suspend Mode
There are three selections for Power Management, and they have fixed
mode settings.
3.7.4 Video Off Method
To select the method to off the video. The Choice : "Blank Screen", "V/H
SYNC+ Blank", "DPMS".
3.7.5 Video Off In Suspend
When system is in suspend, video will turn off. The choices are "No" and
"Yes".
3.7.6 Suspend Type
The Choice : "Stop Grant", "PwrOn Suspend".
3.7.7 Modem Use IRQ
This determines the IRQ in which the MODEM can use.The choices: "3",
"4", "5", "7", "9", "10", "11", "NA".
3.7.8 Soft-Off by PWR-BTTN
If you choose “Instant-Off”, then pushing the ATX soft power switch but-
ton once will switch the system to “system off” power mode. You can
choose “Delay 4 sec.” If you do, then pushing the button for more than 4
seconds will turn off the system, whereas pushing the button momentarily
(for less than 4 seconds) will switch the system to “suspend” mode.
3.7.9 CPU THRM-Throttling
Min Saving Minimum power management., Suspend Mode = 1 hr.,
and HDD Power Down = 15 min.
Max Saving Maximum power management., Suspend Mode = 1 min.,
and HDD Power Down = 1 min.
User Defined
(Default) Allows you to set each mode individually. When not dis-
abled, each of the ranges are from 1 min. to 1 hr. except
for HDD Power Down which ranges from 1 min. to 15 min.
and disable.
