AIMB-744 User’s Manual 16
1.11 Cache Memory
Since the second-level (L2) cache has been embedded into the Intel®
socket 478 Pentium® 4/Celeron™ processor, you do not have to take
care of either SRAM chips or SRAM modules. The built-in second-level
cache in the processor yields much higher performance than the external
cache memories. The cache size in the Intel ® Pentium ® 4 processor is
512/1024 KB. In the Celeron CPU, the cache size is 128/256KB.
1.12 Processor Installation
The AIMB-744 is designed for Intel Pentium® 4 processor/Celeron™
(socket 478) up to 3.4/2.8 GHz with HT technology.
Step 1 : Lift the processor socket lever
Step 2 : Align the corner having the triangle marking on the processor
with the corner where the lever is attached to the socket
Step 3 : Lower the lever to its original position
Note: Slim Heatsink & Fan is available from Advan-
tech. Please contact with Advantech's sales
representative if needed.
