Page 36
AIMB-744 User’s Manual
22
2.9 CPU Fan Connector (CN14)
If fan is used, this connector supports cooling fans of 500mA (6W) or
less.
2.10 System FAN connector (CN15 and CN37)
If fan is used, this connector supports cooling fans of 500mA (6W) or less.
2.11 Front Panel Connectors (CN16, 17, 18, 19, 21&29)
There are several external switches to monitor and control the AIMB-744
2.11.1 Power LED and Keyboard Lock (CN16)
CN14
CN16,17,18,19,21,29
