14 line out, mic in connector (cn55), 15 audio input from cd-rom (cd in; cn56) – Intel Socket 478 AIMB-744 User Manual
Page 39
25
Chapter 2
The AIMB-744 is equipped with one or two high-performance 10/100/
1000 Mbps Ethernet LANs. They are supported by all major network
operating systems. The RJ-45 jacks on the rear plate provide convenient
or 10/100/1000 Base-T operation.
2.14 Line Out, Mic IN connector (CN55)
The Line Out is to output the audio signal to external audio device, like
speakers or headphones. The Mic IN is to input the audio signal via
microphones.
2.15 Audio input from CD-ROM (CD IN; CN56)
The CD IN is a connector for CD-ROM to input the audio signal.
