SMART 108/116 IP
9
Position here for
front facing
Position here
for rear facing
Rear of unit
Front of unit
Figure 3 Bracket positions
Place the brackets towards the front of the unit so that the unit can be mounted
front facing, or place the brackets towards the rear of the unit so that the unit can be
mounted rear facing. Figure 4 illustrates the bracket connected for rear facing.
Screw the bracket to the Smart 108/116 IP using the screws provided.
Bracket connected for rear
facing rack mounting
Rear of unit
Figure 4 Bracket connected
