Motorola WA840G - Manual (Page 47)

SECTION 3 CONFIGURATION
3-10 WA840G
Field Description
Group Key
Renewal Interval This is the number of seconds that pass until
your access point sends out a new group key
and is only available if WPA or 802.1X are
selected.
The default is 300 seconds.
RADIUS Server
IP
RADIUS Server
Port Number
Enter the RADIUS Server IP and Port number.
RADIUS is an authentication and accounting
system to verify users.
To display these fields, either of the following
conditions need to exist:
! Open System is selected, along with either
WEP64 or WEP128, and 802.1X is enabled
! WPA is selected and TKIP or AES is
selected.
The default RADIUS Port Number is 1812.
RADIUS Shared
Secret
RADIUS Shared
Secret
Confirmation
Type and re-type the RADIUS password in
these fields.
