Programming/test cable – Motorola PR400 User Manual
Page 28

July 21, 2004
6881096C24-A
3-4
Test Equipment, Service Aids, and Service Tools: Service Aids
Programming/Test Cable
Figure 3-1. Programming/Test Cable
Figure 3-2. Wiring of the Connectors
25 POSITION
FEMALE CONNECTOR
25 POSITION
MALE CONNECTOR
36.0”
CABLE
36.0”
CABLE
P1
P2
P3
P2
25 pin Male D Connector
Components molded inside
1
5
24
7
20
8
15
16
9
47
ohm
33K
+
1UF,16V 5%
Orange
Blue
White
Spiral
Yellow
P1
2.5mm stereo and
3.5mm
1
2
5
3
4
3.5mm Tip
(Speaker +)
3.5mm
Sleeve
2.5mm Tip
(Microphone)
2.5mm
2.5mm
Center
P3
25 pin Female
D Connector
1
15
4
11
1
2
3
4
5
3.5mm mono
2.5mm stereo
To Test Box
To Test Box
