61
Using the PIP INPUT button
1. To view a PIP image, press .
2. To see the available PIP inputs, press repeatedly. The input
name will be displayed on screen for about five seconds. The
equipment connected to INPUT-1, 2, 3 (DVD component), 4 or
DTV needs to be turned on to show a PIP or POP.
PIP/POP
Using PIP and POP Features, continued
PIP A 017 Ant-A 002 KCBS
Standard
TV-PG DLSV
SQV-1
PAUSE
PIP
Using the ADJUST button with PIP or POP
PIP:
Press to move the PIP image anywhere on the screen.
ADJUST
TV AUDIO
CABLE/DBS/DTV DVD
VCR
POP:
Press to change to a different “live” POP image.
PIP INPUT
PIP CH
PIP INPUT
PIP/POP
PIP CH
ADJUST
PAUSE
PAUSE
PAUSE
PAUSE
ADJUST
PAUSE
Using the PIP CH button
When a PIP or POP channel is displayed, the PIP CH button
can change PIP or POP channels for Ant-A, Ant-B or DTV
(when optional HD-1080 receiver is connected).
1. Press .
2. Press to show a different channel on the PIP or POP.
Using the PAUSE button with PIP, Side-by-Side or
POP (select switch must be in TV position)
PIP:
While viewing a PIP or side-by-side channel, press to freeze
the image. Press again to return to a live picture.
To bring a frozen PIP image on-screen, press .
POP:
Press to keep the same active POP and stop auto-
matic switching.
Press again to return to automatic POP switching.
