Page 37
Chapter 2
2-20
D-Bracket Connector: JDB1
The mainboard comes with a JDB1 connector for you to connect to D-
Bracket. D-Bracket is a USB Bracket integrating four LEDs and allows
users to identify system problem through 16 various combinations of LED
signals. For definitions of 16 signal combinations, please refer to Chapter 1. D-
Bracket.
JDB1
1
9
2
10
D-Bracket
Connected to JDB1
Connected to JUSB1
