GTO UL325 SERIES - Manual (Page 38)

35
Symptom Diagnosis Check
New installation that will not
work. Power Problem
Dip Switch Settings
Transmitter
Antenna Receiver
• Turn Power ON
• Fuse
• Battery Connections
• Turn #5 dip switch OFF
• Program the transmitter
• Replace transmitter battery
• Check Antenna Receiver Connections
Gate opens or closes too far
and blows the fuse. Open or Closed position limit is not
programmed.
Gate Bracket is out of adjustment
• Reset Limits
• Adjust Gate Bracket with arm fully retracted.
Opener obstructs while
disconnected from the gate. Stall Force Adjustment
Power Problem
Operator Arm Problem
• Adjust Stall Force to Maximum
• Battery Under Load
• Test Rev Counter
Open and will not close Power Problem
Shorted Accessory
• Battery Under Load
• Disconnect all hardwired accessories and try
the transmitter.
Hear warning buzzer and the
opener does not work.
One gate stops in the middle
of its cycle or operates
intermittently.
Operator arm won’t work or
works slowly or intermittently.
Power Problem
Bad Relay on PCB
Charging with Transformer:
• Fuse Connection
• Battery Under Load
• Battery Connections
• Charging Circuit
• Transformer
Charging with Solar:
• Weather
• Solar Panel Placement
• Battery Under Load
• Charging Circuit
• Solar Panel
Output of RED & BLK Master Input Terminals with
wires disconnected while pressing the transmitter.
