GTO UL325 SERIES - Manual (Page 17)

14
Mounting Pull-to-Open Opener to Gate
Gate Opener Installation
6
2
1
OPEN gate and re-attach opener with clevis pin. Check for level.
Clamp securely.
U
O
Z
N
7
Secure post pivot bracket to post bracket when clearance is OK
(Step 5) in both open and closed positions.
9 8
Mark middle of post bracket slots on fence post. Mark middle of
gate bracket slots on gate cross support. Remove clamps, post, gate brackets, and opener. Then use a
hammer and center punch to mark hole positions.
P
S
Y
R
11 10
Drill holes completely through gate post and gate cross support. Attach post bracket assembly to fence post. NOTE: Must be
through bolted.
