29 307-712
TECHNICAL DATA
Weight 0.87 Kg (1.90 lb) . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gun Length 310 mm (12.25 in.) . . . . . . . . . . . . . . . . . . . . .
Maximum Working Pressure 7 bar (100 psi) . . . . . . . . . .
Air Pressure Operating Range 0–7 bar (0–100 psi) . . .
Fluid Pressure Operating Range 0–7 bar (0–100 psi) .
Voltage Operating Range 0–75 KV . . . . . . . . . . . . . . . . . .
Paint Resistivity Range 7 megohm cms to infinity . . . .
Air Inlet
Turbine 1/4 npsm(m) L.H. . . . . . . . . . . . . . . . . . . . . . .
Atomizing & Cylinder 1/4 npt(m) . . . . . . . . . . . . . . . .
Fluid Inlet 3/8 npsm(m) . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wetted Parts Stainless Steel, Polyethylene, . . . . . .
Nylon, Acetal, Viton
rr
,
Delrin r
Viton
rr
and Delrin
r
are registered trademarks of
the DuPont Co.
HOW TO ORDER REPLACEMENT PARTS
1. To be sure you receive the correct replacement
parts, kits or accessories, always give all of the
information requested in the chart below.
2. Check the parts list to identify the correct part
number; do not use the ref. no. when ordering.
3. Order all parts from nearest Graco distributor.
6 digit
Part
Number Qty Part Description
SERVICE INFORMATION
Listed below by assembly changed are OLD and NEW
parts.
218–745 OLD 4 100–664 Screw
Spray Gun NEW 4 110–916 Screw
Assembly Ref
Changed Status No. Part No. Name
