Graco Inc. XTR 5 User Manual

5 and xtr, 7 airless spray gun

background image

XTR

5 and XTR

7 Airless Spray Gun

Instructions/Parts

See page 9 for model numbers.
Maximum Working Pressure:

XTR 5: 5000 psi (35 MPa, 345 bar)
XTR 7: 7250 psi (50 MPa, 500 bar)

For use with protective coating materials

312145D

The following warnings are for the setup, use, grounding, maintenance, and repair of this equip-
ment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer
to procedure-specific risks. Refer back to these warnings. Additional product-specific warnings
may be found throughout the body of this manual where applicable.

WARNING

SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This
may look like just a cut, but it is a serious injury that can result in amputation. Get
immediate surgical treatment.

Do not point gun at anyone or at any part of the body.

Do not put your hand over the spray tip.

Do not stop or deflect leaks with your hand, body, glove, or rag.

Do not spray without tip guard and trigger guard installed.

Engage trigger lock when not spraying.

Follow Pressure Relief Procedure in this manual, when you stop spraying and
before cleaning, checking, or servicing equipment.

PRESSURIZED EQUIPMENT HAZARD
Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the
eyes or on skin and cause serious injury.

Follow Pressure Relief Procedure in this manual, when you stop spraying and
before cleaning, checking, or servicing equipment.

Tighten all fluid connections before operating the equipment.

Check hoses, tubes, and couplings daily. Replace worn or damaged parts immedi-
ately.

IMPORTANT SAFETY INSTRUCTIONS.
Refer to your sprayer instruction manual for
pressure relief, priming, and spraying
instructions. Keep these instructions.

ti5045b

II 2 G c T6
