Magnum dx
.015 max. tip size
.24 gpm (.91 lpm)
3/8 HP
Periodic use. Ideal for
spraying up to
125 gallons
(473 L) yearly* • Homeowner • Handyman • Interiors • Fences • Houses • Decks Light to Medium
Magnum XR5
.015 max. tip size
.27 gpm (1.02 lpm)
5/8 HP
13% more output than dx!
Occasional, quarterly use.
Ideal for spraying up to
175 gallons
(662 L) yearly* • Handyman • Remodeler
• Property owner • Interiors • Fences • Houses
• Rental properties • Barns • Decks
Light to Medium
Magnum XR7
.017 max. tip size
.31 gpm (1.17 lpm)
3/4 HP
15% more output than XR5!
Moderate, monthly use.
Ideal for spraying up to
300 gallons
(1136 L) yearly* • Handyman • Remodeler
• Property owner
• Maintenance painter
• General contractor • Interiors • Fences • Houses
• Rental properties • Barns • Decks
• Exterior structures
Light to Medium
Magnum XR9
.019 max. tip size
.38 gpm (1.44 lpm)
7/8 HP
23% more output than XR7!
Frequent, twice-a-month
use. Ideal for spraying up
to 500 gallons
(1893 L) yearly* • Handyman • Remodeler
• Property owner • Maintenance painter
• General contractor
• Small painting contractor • Interiors • Fences • Houses
• Rental properties • Barns • Decks
• Exterior structures
• Small commercial buildings
Light to Heavy
Graco 190
ES
.019 max. tip size
.38 gpm (1.44 lpm)
7/8 HP
Consistent, weekly use.
Ideal for spraying up to
1000 gallons
(3785 L) yearly* • Handyman • Remodeler
• Property owner • Maintenance painter
• General contractor
• Small painting contractor
• Professional painting contractor • Interiors • Fences • Houses
• Rental properties • Barns • Decks
• Exterior structures
• Commercial buildings
Light to Heavy
Why Airless Spray?
It’s faster. . .
• Users can save valuable time versus other methods.
• Up to 10 times* faster than brush applications.
• Up to 4 times faster than roller applications.
It offers uniform coverage. . .
• Easier to apply paint to a variety of surfaces – smooth to rough.
• Even distribution of material on uneven surfaces.
It’s versatile. . .
• Add accessories to expand your productivity and save time.
• Spray most common coatings or use a pressure roller
attachment for interiors or where backrolling is necessary.
It’s more affordable than renting. . .
• Designed with your needs in mind, these sprayers are an
affordable way to use an airless sprayer.
• The sprayer pays for itself in just a few projects!
* Production times provided are based on application time only.
COATINGS
TIP HOLE SIZE
LIGHT
Stains
.011
.013
.015
.017
.019
Enamels Primers
Interior
Paints
Exterior
Paints
MEDIUM HEAVY
How Do I Choose the Right Sprayer?
Ask yourself these 5 simple questions:
1. How often will I spray?
Periodically Quarterly Monthly Twice-a-Month Weekly
2. How many gallons (liters) a year will I spray?
125 gal. (473 L) 175 gal. (662 L) 300 gal. (1136 L)
500 gal. (1893 L) 1000 gal. (3785 L)
3. What sprayable coatings will I use?
Light Medium Heavy
4. What tip sizes can I use?
5. What types of surfaces and projects will I be spraying?
Interiors Exteriors Houses
Rental Properties Commercial Buildings
* Usage guidelines (yearly gallons) are intended to help with product selection. With routine maintenance and care, your sprayer will last many years.
