GarrettCom FT14 - Manual (Page 7)

FT14 and FT14H 10Mb Media Converters Installation and User Guide (09/09)
vi
www GarrettCom com . .
TABLE OF CONTENTS Page
1.0 SPECIFICATIONS ............................................................................... 1
1.1 Technical Specifications ...................................................................... 1
1.2 Summary of models and descriptions: ................................................. 7
2.0 INTRODUCTION ................................................................................. 8
2.1 Inspecting the Package and the Product ............................................... 8
2.2 Product Description ............................................................................. 9
2.3 Features and Benefits ......................................................................... 15
2.4 Applications for FT14’s and hardened FT14H’s ............................... 18
2.5 Full / Half-duplex capability .............................................................. 20
2.6 Link Pass-through, features and options. ........................................... 20
3.0 INSTALLATION ................................................................................. 23
3.1 Locating the Media Converter Unit ................................................... 23
3.2 MC14-TRAY for Rack Mounting of FT14 Series Converters ......... 25
3.3 MC14-TR+PS9 & MC14-TR+PS9X2 for Rack Mounting ............... 26
3.4 DIN-Rail mounting option ................................................................. 28
3.5 Calculating Overall Segment Distance .............................................. 29
