FT14 and FT14H 10Mb Media Converters Installation and User Guide (09/09)
19
www GarrettCom com
.
.
In this application, in a Industrial environment where extended temp. supported units is a
requirement, the existing Twisted pair network can be easily connected to longer distance
through fiber media using Magnum FT14 or FT14H 10 Mb media converters.
Expanding longer distance through Fiber optic
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
Magnum TB14
Media Converter
T
RX
9VDC .3AMP
UP LINK
Link
RX/ACT
RX\ACT
Link
Pw
FIBER
TWISTED PAIR
Lin
k
RX\ACT
Lin
k
ACT
10Base-T Ethernet Segment
