FT14 and FT14H 10Mb Media Converters Installation and User Guide (09/09)
5
www GarrettCom com . .
Connectors, for Media:
RJ-45 Port: Modular 8-Pin female, with “cross-over” up-link switch
Fiber Port: Fiber optic (standard ST type)
Packaging:
Enclosure: Rugged sheet metal (Steel).
Dimensions, Media Converter unit: Height x Width x Depth
FT14 and FT14H: 3.5 in H x 3.0 in W x 1.0 in D (8.9 cm x 7.6 cm x 2.5 cm)
Weight: all FT14 and FT14H mm and sgl.mode models: 4.6 oz. (130g);
power supply –Hd, and =Hi: 3 oz (85g)
Cooling Method: Convection, plus the case is used as a heat sink on “H” models
Media Converter LED Indicators:
LED FT14 FT14S Description
PWR unit unit Steady ON when power applied.
Link(per port) TP, Fiber TP, Fiber * Steady ON when both attached cable
segments are operational at the other end
RX/Act TP, Fiber TP, Fiber Indicates port is receiving packets.
