FT14 and FT14H 10Mb Media Converters Installation and User Guide (09/09)
22
www GarrettCom com
.
.
Fiber
Twisted Pair
Two LINK LED’s, both
ON or both OFF
Magnum FT14
FT14
Media
TX
RX
9V
DC
.
A
M
P
UP LINK
Li
nk
RX
/A
C
RX
\A
CT
L
n
P
wr
FIBER
TWISTED PAIR
Lin
k
Rx
/A
ct
Lin
k
An/F
Ac
t
1 2 3 4 5 6 7 8 9 1
0 11 12 13 14 15 16 17 18 19 20 21 22 23 24
1 2 3 4 5 6 7 8 9 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24
-
The Link-Pass-through in the FT14H models provides the LINK “see-through”
feature desired for managed networks. On the FT14H models, either both LINK LEDs
are lit or neither is lit. And, the FT14 and FT14H’s both operate in transparent half- and
full-duplex mode.
Note that a pair of FT14 or FT14H
media converters in series can
be used to go from an RJ-45
port, through a fiber segment,
and into another RJ-45 port.
Where both media converters
are FT14H’s with Link Pass-
through, the LINK on each
RJ-45 port can “see through” both of the FT14H’s
Media Converters to the other RJ-45 port, as illustrated
in this diagram.
