FT14 and FT14H 10Mb Media Converters Installation and User Guide (09/09)
38
www GarrettCom com
.
.
4.1 Power Requirements, Power Supply Types for FT14 and FT14H
Magnum FT14 Media Converters are power-efficient and can work with an
external AC power supply. Magnum FT14 Media Converters require a nominal 9VDC
input. version The extended temperature –Hd version is used for heavy duty and
industrial applications.
The 9V DC power input has a plug of 2.5mm, center +ve , with 6 ft. cord. The Magnum
FT14 and FT14H media converters are designed to be used with UL listed Class II power
supplies. Detail info. is provided in Technical Specifications Section 1.1.
The FT14H Hardened media converters are designed to provide reliable operation,
withstand higher temperature environments, and provide the direct DC power choices to
the user to deploy in uncontrolled temperature environments.
9VDC
24VDC
-48VDC
