and use an external AC power supply. A metal case with convection cooling is featured.
Magnum FT14 Magnum FT14H
Operation may be in 0° to 50°C ambient temperature. The units can be mounted securely
on a closet wall or metal cabinet, or by using the metal panel mounting clips included.
