3.2 MC14-TRAY for Rack Mounting of FT14 Series Converters
For 19” rack-mounting of Magnum FT14-series Media Converters, a rack-mount tray is
available, MC14-TRAY. The Media Converter units are mounted with their RJ-45 port
and DC power jack in the
back, with either fiber or
BNC cable in the front. Any
mix of the FT14-type Media
Converters may be placed on
a tray, up to a maximum of
16 units. (The mounting
spaces of the MC14-TRAY
are specific to the “14”-
series, and do not permit other models).
