converters secure in the tray, separately removable for service. The dual LEDs
permit viewing operating status of the Media Converters from any angle.
3.4 DIN-Rail mounting option
The Magnum FT14 and FT14H Media Converters, designed for use in
“Factory Floor” Industrial Ethernet environments, are also available for DIN-Rail
mounting in an enclosure having DIN Rails.
The metal DIN-Rail mounting
hardware is optional and needs to be ordered as a
separate item, e.g. Model # DIN-RAIL-MC2. It
comes with four screws to attach the bracket to
the MC unit.
The Magnum FT14 Models with “HR”
have 24VDC power, and have the DIN-Rail-MC2
bracket included and assembled with the MC unit
at the factory.
