Magnum 6K25 Managed Fiber Switch Installation and User Guide (04/06)
47
www GarrettCom com . .
FULL/HALF
1 ACTIVITY
LINK
2
3
3
2
1
8- Port@ 100Mbps multi-mode LC fiber port
2 4 6
LK LK LK
ACT
F/
ACT
F/
ACT
F/H ACT
F/H
2 4 6
LK LK LK
ACT
F/
ACT
F/
ACT
F/H ACT
F/H
1 3 5
When installed in a Magnum 6K25 Switch, it supports the standard distances as
mentioned on 5.2.3. and the LEDs also
act similarly.
5.2.7
6KP8-MLC, 8 ports @
100Mbps multi-mode LC
connector Small-
Form Factor
Magnum 6KP8-MLC is a
eight-port multi-mode fiber LC
connector “small-form-factor” used
primarily in 100Mbps fiber-to-the-
desktop links.
When installed in a Magnum 6K25 Switch, it supports fiber optic cable distances up to
the IEEE-standard 100Mbps distance limits, i.e., typically 2km at full-duplex and 412m
at half-duplex.The compact size of the LC Connector reduces the size of wiring panels in
wiring closets while providing the advantage of “future-proof” fiber optic
technology.The cable end is a “plug-in” connector with both fiber strands terminated in
one housing that cannot be improperly inserted. Each port has an Activity (ACT) LED
indicating packets being received, a Link (LK) LED indicating proper connectivity with
the remote device when lit, and a FDX/HDX LED indicating full-duplex mode when lit
(or half-duplex when off).
5.2.8 6KP8-45LC, Combo 4@ 100Mbps multi-mode -LC small-form
factor and 4@ 10/100 Mbps RJ-45 Connector
The Magnum 6KP8-45LC Module is a combo module with a combination of
copper and Fiber (Small Form
Factor) LC type ports. The
small size of LC connectors
give an advantage of having
more ports on one module. The
6KP8-45LC is equipped with 4
10/100 RJ-45 ports and 4 LC(
Small form factor) multi-mode
fiber ports.
When installed in a Magnum
6K25 Switch, it supports the
4
3 2 4 6
LK LK LK
AC
F/H
AC
F/H
2
ACT
F/H ACT
F/H
4 Port@ 10/100Mbps & 4 port @ 100Mbps
Multi-Mod LC Fiber port
1 3 5
10/10 LK
1
F/ ACT
4
FULL/HALF
1
ACTIVITY
LINK 2
3
10/10
