GarrettCom 6K25 User Manual
Page 10
Magnum 6K25 Managed Fiber Switch Installation and User Guide (04/06)
3
www GarrettCom com
.
.
For DC internal power supplies at –48VDC, 24VDC and 125VDC, including
Dual Source options (
for continuity of operation when either of the DC input sources
are interrupted)
, see Appendices B and C.
Per-port MDI or MDIX on RJ-45
The copper daughter board has MDI-MDIX Auto-crossover on all the RJ-45
ports., and eliminate the use of cross-over cable between the devices. Also port-
specific user settings (such as FDX or HDX, copper 10/100 speed) can be fixed
using software commands.
Alarm Contact (Optional)
Alarm Contact option is offered as a configuration option. The two alarm contacts
are SPST NC Form-C relays, and an open condition indicates abnormal status. The
Hardware Alarm monitors internal power on the main board, and the Software
Alarm is activated by one or more user-selected software traps.
Agency
Approvals
UL listed (UL60950), cUL, CE, Emissions meet FCC Part 15 Class A
NEBS Level 3 and ETSI Certified for Carrier Central Offices
IEEE 1613 Class 2 Environmental Standard for Electric Power Substations
See
also
Note for Power Substations in Section 3.2.4, 3.6.1, and 5.2.9
IEC 61850 EMC and Operating Conditions Class C for Power Substations
Warranty:
Three years, return to factory
Made in USA
NEBS Testing and Certification: NEBS certified
for details.
