section 4
engine Dc contRol sYsteM
CIRCUIT CONdITION - REST:
Battery voltage is supplied to components of the control system from the unit BATTERY via the RED battery cable
connected to the contacts of the starter contactor (SC), wire 13, a 10 Amp fuse (F1), and Wire 15.
Wire 13 is unfused battery supply voltage and is connected to the contacts of the Starter Contactor Relay (SCR).
Wire 15 12 VDC fused battery supply voltage is supplied to the SCR coil, it goes through the coil and comes out
as wire 17 12 VDC, wire 17 is connected to the Start-Run-Stop switch (SW1) and is held open to ground. No cur-
rent flows through the circuit and the SCR is de-energized.
Wire 15 12 VDC fused battery supply voltage is supplied to SW1 and is held open to Wire 167.
Wire 15 12 VDC fused battery supply voltage is supplied to the Start-Stop Relay (SSR) it goes through the coil
and comes out as wire 229 12 VDC, wire 229 is connected to the printed circuit board and is held open to ground.
No current flows through the circuit and the SSR is de-energized.
