Identification – Grizzly G1095/G1096 User Manual
Page 9
Model g1095/g1096 1-hp power Feeder
-7-
identification
horizontal
handwheel
Vertical travel
handcrank
horizontal
travel lock
Figure 1. Controls and features.
Motor
Assembly
rotary Movement lock
Vertical
travel
lock
lower elbow
Joint lock
upper elbow
Joint lock
power Feeder
swivel lock
refer to
Figure 1 and your power feeder to familiarize yourself with the controls, features, and terminology
used in this manual. doing so will make setup, use, and any future maintenance easy.
gearbox oil
plug
