Grizzly G1095/G1096 User Manual
Page 31
Model g1095/g1096 1-hp power Feeder
-29-
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
101
P6203
BALL BEARING 6203
144
P1096144
WORM GEAR
102
P1096102
GREASE FITTING
150
P1096150
SPECIAL O-RING 101.19 X 3.53
103
P1096103
SPROCKET CASE
151
P1096151
WORM GEAR BOX COVER
104
P1096104
TORSION SPRING 3.8 X 102
152
P1096152
OIL SEAL
105
P1096105
CASE COVER
153
PSB24M
CAP SCREW M5-.8 X 16
107
P1096107
SPROCKET CASE
155
PW01
FLAT WASHER 1/2
108
P1096108
TORSION SPRING 3.8 X 102
156
PN09M
HEX NUT M12-1.75
109
P1096109
CASE COVER
157
P1096157
WORM GEAR SHAFT
110
P1096110
ROLLER SUPPORT
158
P1096158
SPECIAL KEY
111
P1096111
SPROCKET
162
P1096162
GEAR 25T
112
PLW03M
LOCK WASHER 6MM
163
PSB12M
CAP SCREW M8-1.25 X 40
113
PSB01M
CAP SCREW M6-1 X 16
164
P1096164
GEAR 40T
114
PLW04M
LOCK WASHER 8MM
168
P1096168
LUBRICATOR
116
P1096116
CHAIN
170
P1095170
MOTOR 220V, 2-SPD, 1-PH (G1095)
117
P1096117
TUBE
P1096170
MOTOR 220V, 2-SPD, 3-PH (G1096)
118
PR58M
EXT RETAINING RING 24MM
170-1 P1096170-1
SWITCH W/ELECTRICAL BOX
119
P1096119
SPROCKET SHAFT
170-2 P1096170-2
BOX COVER
120
PR47M
EXT RETAINING RING 13MM
170-3 P1096170-3
FAN COVER
122
PW01
FLAT WASHER 1/2
170-4 P1095170-4
MOTOR FAN (G1095)
123
PN09M
HEX NUT M12-1.75
P1096170-4
MOTOR FAN (G1096)
124
P1096124
GREASE FITTING
170-5 PC035A
CAPACITOR 35MFD 250VAC (G1095)
125
P1096125
ROLLER SPINDLE
170-6 P1096170-6
SEALING RING
126
P1096126
SPECIAL HEX BOLT M12-1.75
175
PORS028
O-RING 27.5 X 2.0 S28
127
P1096127
KNOB
177
P1096177
CAP
128
P1096128
OIL CAP
179
PSB50M
CAP SCREW M5-.8 X 10
129
PORP015
O-RING 14.8 X 2.4 P15
181
P1096181
BACK COVER
130
P1096130
CASTING
187
G4182
ROLLER
131
P1096131
BUSHING
188
PLW05M
LOCK WASHER 12MM
132
PSS01M
SET SCREW M6-1 X 10
189
PR09M
EXT RETAINING RING 20MM
136
P1096136
SPROCKET
190
PB09M
HEX BOLT M8-1.25 X 20
137
P1096137
CHAIN
191
PLW04M
LOCK WASHER 8MM
138
P1096138
DOUBLE SPROCKET
192
P1096192
GREASE FITTING
139
P1096139
CHAIN
193
P1096193
SPROCKET SHAFT
