Model h8192 (Mfg. Since 8/07)
-3-
The information contained herein is deemed accurate as of 2/7/2011 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2 Model H8192
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL H8192 1" X 8" BELT/DISC SANDER
Product Dimensions:
Weight............................................................................................................................................................. 58.5 lbs.
Width (side-to-side) x Depth (front-to-back) x Height............................................................... 19-1/2 x 26 x 14-1/2 in.
Footprint (Length x Width)..................................................................................................................... 11 x 18-1/4 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight................................................................................................................................................................ 62 lbs.
Length x Width x Height....................................................................................................................... 21 x 13 x 15 in.
Electrical:
Minimum Circuit Size.............................................................................................................................................. 15A
Switch........................................................................................................... Toggle-Type with Safety Disableing Key
Switch Voltage........................................................................................................................................................ 110
Plug Included..................................................................................................................................... Yes, NEMA 5-15
Motors:
Main
Type................................................................................................................. TEFC Capacitor-Start Induction
Horsepower................................................................................................................................................... 1/3
Voltage......................................................................................................................................................... 110
Prewired....................................................................................................................................................... 110
Phase....................................................................................................................................................... Single
Amps................................................................................................................................................................ 4
Speed......................................................................................................................................................... 1725
Cycle............................................................................................................................................................... 60
Number of Speeds.............................................................................................................................................
Power Transfer ............................................................................................................ V-Belt and Direct Drive
Bearings................................................................................................. Sheilded and Permanently Lubricated
Main Specifications:
Table Info
Miter Gauge Slot Width........................................................................................................................... 12 mm
Miter Gauge Slot Height............................................................................................................................ 5 mm
Belt Table Length......................................................................................................................................... 7 in.
Belt Table Width.......................................................................................................................................... 6 in.
Belt Table Thickness.............................................................................................................................. 9/16 in.
Disc Table Length...................................................................................................................................... 10 in.
Disc Table Width.......................................................................................................................................... 4 in.
Disc Table Thickness................................................................................................................................ 3/4 in.
Machine Data Sheet
