-20-
Model h8192 (Mfg. Since 8/07)
Note: To prevent burning the workpiece and
overloading the sanding disc, move the workpiece
slowly back and forth from the left side of the
sanding disc to the center.
figure 24. Example of 90° disc sanding.
5. Slowly, and with light pressure, move the
workpiece into the left side of the sanding
disc. See
figures 24–26 for examples of disc
sanding.
figure 25. Example of miter sanding.
figure 26. Example of angle sanding.
Belt Sanding
Use the sanding belt for the long, flat surfaces of
the workpiece.
To avoid the risk of kickback and personal
injury, always keep the workpiece firmly on
the table, and never sand the short side of
the workpiece with the sanding belt.
To use the sanding belt:
1. diSConnECt thE SAndEr FroM
poWEr!
2. Using a protractor or other angle measuring
tool, set the correct angle of the sanding belt
table for your operation.
3. Connect the sander to power, turn it ON, and
allow it to reach full speed.
4. place the workpiece on the sanding belt
table, then slowly, and with light pressure,
move the workpiece into the sanding belt.
Note: Hold the workpiece firmly on the table,
but keep your fingers away from the sanding
surface, as shown in
Figure 27.
figure 27. Example of belt sanding.
