Grizzly H8192 - Manual (Page 31)

Model h8192 (Mfg. Since 8/07)
-29-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PSB47M CAP SCREW M10-1.5 X 40 56-2 PH8192056-2 CAPACITOR COVER
2 PW04M FLAT WASHER 10MM 57 PN03M HEX NUT M8-1.25
3 PH8192003 TORSION SPRING 58 PLW04M LOCK WASHER 8MM
4 PH8192004 SPACER 59 PW01M FLAT WASHER 8MM
5 PH8192005 TRACKING KNOB 60 PCB01M CARRIAGE BOLT M8-1.25 X 20
6 PH8192006 COMPRESSION SPRING 61 PH8192061 BASE
7 PH8192007 TRACKING BRACKET 62 PS07M PHLP HD SCR M4-.7 X 8
8 PRP42M ROLL PIN 3 X 20 63 PW05M FLAT WASHER 4MM
9 PH8192009 SHAFT 64 PB03M HEX BOLT M8-1.25 X 16
10 PH8192010 SHAFT 65 PLW04M LOCK WASHER 8MM
11 PSS05M SET SCREW M5-.8 X 10 66 PW01M FLAT WASHER 8MM
12 PSS05M SET SCREW M5-.8 X 10 67 PH8192067 RUBBER FOOT
13 PH8192013 BELT DRIVE PULLEY 68 PW01M FLAT WASHER 8MM
14 PH8192014 RETAINING PLATE 69 PN03M HEX NUT M8-1.25
15 PS07M PHLP HD SCR M4-.7 X 8 70 PW04M FLAT WASHER 10MM
16 PTLW01M EXT TOOTH WASHER 4MM 71 PLW06M LOCK WASHER 10MM
17 P6202 BALL BEARING 6202ZZ 72 PSB64M CAP SCREW M10-1.5 X 25
18 PK23M KEY 5 X 5 X 25 80 PAW02.5M HEX WRENCH 2.5MM
19 PH8192019 SHAFT 81 PAW08M HEX WRENCH 8MM
20 P6002 BALL BEARING 6002ZZ 99 PH8192099 SANDING DISC 8"
21 PH8192021 BELT HOUSING 100 PH8192100 SANDING DISC PLATE 8"
22 P6202 BALL BEARING 6202ZZ 101 PSS31M SET SCREW M5-.8 X 8
23 PH8192023 UPPER BELT PULLEY 102 PS78M PHLP HD SCR M4-.7 X 45
24 PW03M FLAT WASHER 6MM 104 PS07M PHLP HD SCR M4-.7 X 8
25 PLW03M LOCK WASHER 6MM 105 PW05M FLAT WASHER 4MM
26 PSB04M CAP SCREW M6-1 X 10 106 PH8192106 V-BELT SAFETY COVER
27 PSB146M CAP SCREW M10-1.5 X 15 107 PVM19 V-BELT M-19 0580
28 PLW06M LOCK WASHER 10MM 108 PH8192108 V-BELT REAR COVER
29 PW04M FLAT WASHER 10MM 109 PWN03M WING NUT M4-.7
30 PH8192030 BELT SUPPORT 110 PH8192110 MITER GUAGE
32 P6202 BALL BEARING 6202ZZ 120 PH8192120 DISC TABLE
33 PH8192033 MIDDLE BELT PULLEY 121 PRP78M ROLL PIN 4 X 10
34 PR05M EXT RETAINING RING 15MM 122 PH8192122 ARC KEY
35 PSS53M SET SCREW M5-.8 X 12 123 PH8192123 ANGLE SCALE
36 PH8192036 LOWER BELT PULLEY 124 PH8192124 RIVET
37 PH8192037 SANDING BELT 1" X 42" 125 PW04M FLAT WASHER 10MM
38 PN01M HEX NUT M6-1 127 PH8192127 DUST PORT 2"
39 PH8192039 THREADED STUD M6-1 X 12 128 PW03M FLAT WASHER 6MM
41 PH8192041 BELT COVER KNOB 129 PS14M PHLP HD SCR M6-1 X 12
43 PH8192043 BELT COVER 130 PH8192130 DUST COVER
45 PH8192045 BELT TABLE 131 PS07M PHLP HD SCR M4-.7 X 8
46 PSS57M SET SCREW M5-.8 X 20 132 PH8192132 DISC COVER
47 PH8192047 TABLE LOCK 133 PH8192133 POINTER
48 PW04M FLAT WASHER 10MM 134 PS07M PHLP HD SCR M4-.7 X 8
49 PH8192049 BELT TABLE SUPPORT 135 PN02M HEX NUT M10-1.5
50 PW04M FLAT WASHER 10MM 136 PW04M FLAT WASHER 10MM
51 PLW06M LOCK WASHER 10MM 137 PH8192137 SWITCH W/SAFETY TAB
52 PB70M HEX BOLT M10-1.5 X 16 139 PH8192139 SWITCH COVER
53 PSS05M SET SCREW M5-.8 X 10 140 PS07M PHLP HD SCR M4-.7 X 8
54 PH8192054 MOTOR PULLEY 141 PH8192141 POWER CORD
55 PK112M KEY 5 X 5 X 55 142 PH8192142 STRAIN RELIEF
56 PH8192056 MOTOR 1/3HP,110V,1-PH 143 PS07M PHLP HD SCR M4-.7 X 8
56-1 PH8192056-1 START CAPACITOR 240MF 125VAC 144 PH8192144 CLAMP
parts List
