8
Model Gas
CAT.
Gas
Type
Working
Pressure
Aeration Injector Gas Rate
m3/h
Input kW (Gross) Country
High Low
Studio 1 BF 12H Natural
G20
20mbar 16 x 23 400 0.600 6.3 3.0 GB, IE
Studio 1 BF 13P
Propane
G31 37mbar
14 x 16 (1)
16 x 23 (1) 185 0.230 6.1 3.0 GB, IE
Studio 2 BF 12H Natural
G20
20nbar 14 X 16 600 0.800 8.4 4.3 GB, IE
Studio 2 BF 13P
Propane
G31 37 mbar
14 x 16 (1)
16 x 23 (1) 225 0.275 7.3 4.0 GB, IE
Efficiency Class 2 - 81% / NOx Class 4
Flue Outlet Size Ø 150mm
Flue Inlet Size Ø 100mm
Gas Inlet Connection Size Ø 8mm
RESTRICTOR REQUIREMENT
VERTICAL & HORIZONTAL FLUE
STUDIO 1 BF STUDIO 2 BF
Vertical Flue Height Horizontal Length Restrictor
Size
Vertical Flue Height Horizontal Length Restrictor Size
200mm - 500mm Up to 500mm No restrictor 700mm - 1490mm Up to 1000mm No restrictor
500mm - 100mm Up to 1000mm No restrictor 1500mm - 2490mm Up to 5000mm No restrictor
1000mm - 1490mm Up to 1000mm 70mm Ø 2500mm - 3000mm Up to 5000mm 75mm Ø
1500mm - 1990mm Up to 5000mm 70mm Ø
2000mm - 3000mm Up to 5000mm 60mm Ø
TOP EXIT - VERTICAL ONLY INCLUDING OFFSET
STUDIO 1 BF STUDIO 2 BF
Vertical Flue Height Restrictor Size Vertical Flue Height Restrictor Size
3000 - 4990mm Ø 52mm 3000mm - 4990mm Ø 60mm
5000mm - 10,000mm Ø 47mm 5000mm - 10,000mm Ø 52mm
INSTALLATION INSTRUCTIONS
TECHNICAL SPECIFICATION
COVERING THE FOLLOWING MODELS:
STUDIO 1 BF: STUDIO 2 BF:
8700BFCHEC 8701BFCHEC
P8700BFCHEC P8701BFCHEC
