Grizzly G0636X User Manual
Page 57
G0636X 17" Ultimate Bandsaw
-55-
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
191
PSB06M
CAP SCREW M6-1 X 25
225
P0636X225 SLIDING PLATE
192
P0636X192 HANDWHEEL
226
P0636X226 FIBER WASHER 13MM
193
P0636X193 SWITCH BUSHING
227
P0636X227 STEP SCREW
194
PSS07M
SET SCREW M5-.8 X 5
228
PSB04M
CAP SCREW M6-1 X 10
195
P0636X195 BUSHING
229
PLW03M
LOCK WASHER 6MM
196
PSBS22M
BUTTON HD CAP SCR M8-1.25 X 20
230
PW03M
FLAT WASHER 6MM
197
PW01M
FLAT WASHER 8MM
231
PSB60M
CAP SCREW M8-1.25 X 55
198
P0636X198 SUPPORT PLATE
232
PW01M
FLAT WASHER 8MM
199
P0636X199 LOWER GUIDE BRACKET
233
P0636X233 SLIDING PLATE
200
PN05M
HEX NUT M16-1.5
234
PLN04M
LOCK NUT M8-1.25
201
P0636X201 WORM CYLINDER
235
PB83M
HEX BOLT M6-1 X 16
202
P0636X202 WORM GEAR
236
PSB01M
CAP SCREW M6-1 X 16
203
P0636X203 FIXED PLATE
237
PW03M
FLAT WASHER 6MM
204
P0636X204 FIXED BOLT
238
P0636X238 LOWER SUPPORT BRACKET
205
P0636X205 COVER
239
P0636X239 SHAFT
206
PLW04M
LOCK WASHER 8MM
240
P0636X240 UPPER BLADE GUIDE SUPPORT
207
PSB11M
CAP SCREW M8-1.25 X 16
241
PB83M
HEX BOLT M6-1 X 16
208
PFS07M
FLANGE SCREW M5-.8 X 10
242
P0636X242 BIAS SHAFT
209
P0636X209 COVER
243
PR05M
EXT RETAINING RING 15MM
210
PN06M
HEX NUT M5-.8
244
P6202
BALL BEARING 6202ZZ
211
PFH19M
FLAT HD SCR M4-.7 X 10
245
P0636X245 HANDLE BUSHING
212
P0636X212 RACK
246
PSB29M
CAP SCREW M6-1 X 40
213
P0636X213 EXTENSION RACK
247
PR03M
EXT RETAINING RING 12MM
214
P0636X214 SQUARE TUBE
248
P6201
BALL BEARING 6201ZZ
218
PSB14M
CAP SCREW M8-1.25 X 20
249
P0636X249 UPPER SPACING SLEEVE
219
PSB04M
CAP SCREW M6-1 X 10
250
P0636X250 SHAFT
220
PLW03M
LOCK WASHER 6MM
251
PWR1013
WRENCH 10 X 13
221
PW03M
FLAT WASHER 6MM
252
PWR1719
WRENCH 17 X 19
222
P0636X222 SUPPORT PLATE
253
PAW05M
HEX WRENCH 5MM
223
PW03M
FLAT WASHER 6MM
254
PAW06M
HEX WRENCH 6MM
224
P0636X224 PROTECT COVER (ASM)
255
P0636X255 EYE BOLT M10-1.5- X 15
