G0636X 17" Ultimate Bandsaw
-53-
Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0636X001 HANDLE 55 P0636X055 ADJUST BOLT
2 P0636X002 LEVER ROD M16-2 56 PB73M HEX BOLT M10-1.5 X 50
3 PN13M HEX NUT M16-2 57 PN02M HEX NUT M10-1.5
4 P0636X004 ROTATE SHAFT 58 PW04M FLAT WASHER 10MM
5 PSB25M BUTTON HD CAP SCR M10-1.5 X 20 59 PSS04M SET SCREW M6-1 X 12
6 PLW06M LOCK WASHER 10MM 60 P0636X060 PULLEY
7 P0636X007 BLADE TRACKING KNOB M10-1.5 x 25 61 PW01M FLAT WASHER 8MM
8 P0636X008 BLADE TRACKING LOCK LEVER 10MM 62 P0636X062 LOWER SHAFT
9 P0636X009 GUIDE POST LOCK KNOB M10-1.5 X 25 63 PSBS22M BUTTON HD CAP SCR M8-1.25 X 20
10 P0636X010 MACHINE BODY 64 P0636X064 PULLEY
11 P0636X011 PILLOW BLOCK 65 PVA33 V-BELT A-33 4L330
12 P0636X012 CAM 66 P0636X066 LOWER WHEEL
13 PSB31M CAP SCREW M8-1.25 X 25 67 P0636X067 TRANSLUCENT PIECE
14 PB82M HEX BOLT M8-1.25 X 80 68 P0636X068 RIVET 3.2 X 10
15 PN03M HEX NUT M8-1.25 69 PLN03M LOCK NUT M6-1
16 P0636X016 UPPER WHEEL HINGE 70 PS26M PHLP HD SCR M6-1 X 20
17 P0636X017 SQUARE SHAFT 71 P0636X071 KNOB
18 P0636X018 SPECIAL WASHER 8MM 72 P0636X072 HEIGHT POINTER
19 PSB14M CAP SCREW M8-1.25 X 20 73 PFS07M FLANGE SCREW M5-.8 X 10
20 PFH39M FLAT HD SCR M5-.8 X 16 74 PSB02M CAP SCREW M6-1 X 20
21 P0636X021 LOCATE PLATE 75 P0636X075 BLADE TENSION HANDLEWHEEL
22 PSS75M SET SCREW M10-1.5 X 16 76 P0636X076 LOWER WHEEL SUPPORT
23 P0636X023 GUIDE BLOCK 77 PW03M FLAT WASHER 6MM
24 PSS07M SET SCREW M5-.8 X 5 78 PFS11M FLANGE SCREW M6-1 X 10
25 P0636X025 COMPRESSION SPRING 79 P0636X079 BUSHING
26 P0636X026 BUSHING 80 P0636X080 BRAKE LEVER
27 P0636X027 PRESS BLOCK 81 PSB01M CAP SCREW M6-1 X 16
28 P51201 THRUST BEARING 51201 82 PN01M HEX NUT M6-1
29 P0636X029 BLADE TENSION SHAFT 83 P0636X083 EXTENSION SPRING
30 P0636X030 TENSION LINE 84 P0636X084 BRAKE STEP PLATE
31 P0636X031 UPPER WHEEL SHAFT 85 PN04M HEX NUT M4-.7
32 P6306ZZ BALL BEARING 6306ZZ 86 P0636X086 LIMIT SWITCH KL7141
33 PR64M INT RETAINING RING 72MM 87 PS51M PHLP HD SCR M4-.7 X 30
34 P0636X034 BUSHING 88 P0636X088 CORD CLAMP 5/8"
35 P0636X035 UPPER WHEEL 89 PHTEK4M TAP SCREW M4 X 8
36 P0636X036 BRAKE PAD 90 P0636X090 BRAKE LEVER CORD
37 PLW04M LOCK WASHER 8MM 91 P0636X091 CORD BUSHING
38 P0636X038 UPPER WHEEL SLIDING BRACKET 92 P0636X092 PROTECT TUBE 1/2" X 43-5/16"
39 P0636X039 COMPRESSION SPRING 93 P0636X093 BRUSH
40 P0636X040 GUIDE PIN 3 X 12 94 P0636X094 MOTOR 5HP
41 P0636X041 MOVING PLATE 94-1 P0636X094-1 MOTOR COVER
42 P0636X042 FIX PLATE 94-2 P0636X094-2 MOTOR FAN
43 PHTEK15M TAP SCREW M4 X 10 94-3 P0636X094-3 CAPACITOR COVER
44 PW05M FLAT WASHER 4MM 94-4 P0636X094-4 START CAPACITOR 400MFD 250VAC
45 P0636X045 TENSION POINTER 94-5 P0636X094-5 RUN CAPACITOR 40MFD 350VAC
46 P0636X046 TAP SCREW M4 X 15 94-6 P0636X094-6 JUNCTION BOX
47 P0636X047 TENSION SCALE 95 P0636X095 ADJUSTMENT HUB COVER
48 P0636X048 START SWITCH 96 PSBS22M BUTTON HD CAP SCR M8-1.25 X 20
49 P0636X049 STOP SWITCH 97 P0636X097 SET BOLT M10-1.5 X 30
50 P0636X050 KEY SWITCH 98 P0636X098 CORD CLAMP 1/2"
51 P0636X051 SWITCH PLATE 99 PFS09M FLANGE SCREW M5-.8 X 50
52 P0636X052 CONNECTING CORD 100 P0636X100 TERMINAL BOX
53 P0636X053 CONNECTING CORD 101 PS52M PHLP HD SCR M4-.7 X 20
54 P0636X054 SWITCH CORD 102 P0636X102 TERMINAL HOUSE
