■ ■ 14 GE Zenith Controls ■ ■
ZTX Operation and Maintenance Manual (72R-1000)
Replacement Parts
(cont’d)
Standard Transition - 225 to 400 Amps
Stock Numbers by Amperage
Tag Description
Recommended
as Spares 225, 250* 260, 300* 400
Cable Connection Lug S-2701 N 1,2,3 N
E 1,2,3 N
T 1,2,3 N
Wire Size #4-600 MCM #4-600 MCM
Coil Volts
208/220/240 K-2246B CN/CE Solenoid *
SN/SE Position Sense Limit Switch
A3/A4 Auxiliary Contacts
L-3078
BR Rectifier * PS-5076
S-2701 S-2701
#6-250 MCM
T1 T2 T3 TN
E1 E2 E3 EN
SN
A4
SE
A3
CN/CE
BR
N1 N2 N3 NN
Figure 15
Table 8
