10. INSTALLATION
10-17
Setting DATA 4 to DGPS
An external DGPS receiver can be connected to the DATA 4 port.
Follow the procedure below to setup the GP-150-DUAL according to the
specifications of the DGPS receiver.
1) Press MENU ESC, 9 and 5.
2) Press to select Level.
3) Press or to select level; RS232C or RS422.
4) Press the CU/NU ENT key.
5) Press to select DGPS.
6) Press to select To Next Page.
DATA 4 I/O SETUP 2/2
To Previous Page
First Bit
Parity
Stop Bit
Baud Rate
: Select
ENT: Enter MENU: Escape
MSB LSB
EVEN ODD NONE
1
2
4800 9600
I/O SETUP 2/2 menu
7) Press S or T to select First Bit.
8) Press W or X to select first bit; MSB or LSB.
9) Press to select Parity.
10) Press or to select parity bit; EVEN, ODD or NONE.
11) Press to select Stop Bit.
12) Press or to select stop bit; 1 or 2.
13) Press to select Baud Rate.
14) Press or to select baud rate; 4800 or 9600.
15) Press the CU/NU ENT key.
16) Press the MENU ESC key.
