9-1
9. INSTALLATION
9.1 Equipment Lists
Standard Supply
Optional Supply
9.2 Installation of Receiver Unit
9.2.1 Installation consideration
The receiver unit can be installed on a desktop, underside of table or in a panel. Refer
to the outline drawings at the end of this manual for installation instructions. When se-
lecting a mounting location, keep in mind the following points:
• Locate the unit away from exhaust pipes and vents.
• The mounting location should be well ventilated.
• Mount the unit where shock and vibration are minimal.
Name Type Code No. Qty Remarks
Receiver unit GP-33 - 1
Antenna Unit GPA-017 - 1 w/10 m cable
Installation Materials CP20-03300 - 1 set -M12-05BM+05BF-060
-CP20-03310
Accessories FP20-01200 - 1 set See the packing list at the
back of this manual.
Name Type Qty Remarks
Junction Box FI-5002 000-010-765
Cable Assy. FRU-10BFFM-
02M 001-112-970-10
Right Angle Antenna
Base NO.13-QA330 001-111-910-10 For mounting the anten-
na unit, select one.(See
the installation proce-
dure at the back of this
manual.)
L-type Antenna Base NO.13-QA310 001-111-900-10
Handrail Antenna
Base NO.13-RC5160 001-111-920-10
Mast Mounting Kit CP20-01111 004-365-780
NMEA Connector SS-050505-FMF-
TS001 000-168-603-10 CAN bus distributor, mi-
cro style
NC-050505FMF-
TS001 000-160-507-10 CAN bus distributor,
mini style
