6.MAINTENANCE & TROUBLESHOOTING
6-3
PROCESSOR UNIT TEST
ROM OK
No. 6454002-**.**
RAM OK
EEPROM OK
RUDDER ANGLE OK
CLUTCH/BYPASS OK
REMOTECONTROLLER1 ON 1
REMOTECONTROLLER2 NOT USED
INPUT VOLTAGE 24.8 V
HEADING SENSOR - -
PORT1 - -
PORT2 - -
RS232 - -
PROCESSOR UNIT
**.**: Program version no.
For factory setting
CONTROLLER UNIT TEST
ROM OK
No. 6454001-**.**
RAM OK
COMUNICATION OK
EEPROM OK
CONTROLLER ID
CONTROLLER UNIT
**.**: Program version no.
HEADING SENSOR TEST
This test should be done while turning the connected sensor (PG-500) in a circle
with 3°/sec. or more. If the sensor is not rotate, this test terminates after one
minute with NG result.
ROM OK
No. 6454101-**.**
RAM OK
EEPROM OK
SENSOR OK
RATE SENSOR OK
HEADING SENSOR
**.**: Program vrsion no.
