Furuno NAVpilot NAVpilot-500 User Manual
Page 18
2. BASIC OPERATION
2-9
4. Rotate the [ENTER] knob to select “ANALOG INDIACATOR BAR” on the
second page.
5. Press the [ENTER] knob to show the bar indicator options window.
DEVIATION
RUDDER/XTE
DEVIATION/XTE
RUDDER ANGLE
Analog indicator bar options window
6. Rotate the [ENTER] knob to select option you desired to show.
Note the following.
RUDDER/XTE: Rudder in STBY and AUTO mode, XTE in NAV mode.
DEVIATION/XTE: Deviation in STBY and AUTO mode, XTE in NAV mode.
7. Press the [ENTER] knob.
8. Press the [MENU] key to close the menu.
