4-6
Print phohibit areas on the front and back surfaces
Printing in area A on the front of a document may, in a rare case, cause a document size detection
error. Printing in area B on the front and back of document may, in a rare case, result in a double feed
error. Figure 4.2 shows print prohibit areas on the front and back surfaces.
NOTE
Figure 4.2 shows the document as viewed from the reading surface.
Figure 4.2 Print prohibit areas on the front and back surfaces
113 (4.45") 134 (5.28")
79 (3.12") 96 (3.78")
10
(0.39")
15
Document feeding dir
ection
Unit : mm
Top of document
Bottom of document
Center of document
10
(0.39") 34 (1.34")
10
(0.39")
10
(0.39")
: Area A
: Area B
Reading
reference
position
Front side
Reading surface
