6-52
1. Put sheets of paper on the hopper table.
2. In the <> initial screen, press
ENTER
.
The <> menu screen (Offline
Feed Test) appears.
3. Press
ENTER
again.
The scanning parameters screen indicates the
current parameters with START blinking (blinking
indicates “selectable”).
4. Press .
SETUP blinks (blinking indicates “selectable”).
5. Press ENTER .
The LCD changes to the parameter set screen
with S (simplex mode) blinking (blinking indicates
“selectable”).
6. Press .
A4P (A4 size in portrait orientation) blinks
(blinking indicates “selectable”).
Offline feed test
This function scans sheets of paper continuously for checking entire operation of the mechanism
without a host computer. You can use the Settings function in setup mode to modify scanning
parameters (scanning mode, paper size/orientation, density, resolution, and halftone processing) for
scanning documents.
Remarks
START: begins the test.
SETUP: changes settings of scanning
parameters.
LCD display
Offline Feed Test
Test items
START and SETUP
The following is an example of operation when you start the offline feed test.
<>
<>
Offline Feed Test
S A4P 200 LA
START SETUP
S A4P 200 LA
START SETUP
S A4P 200 LA
LA
S A4P 200 LA
LA
