FieldServer Data Aire (DAP) FS-8704-49 - Manual (Page 43)

FS-8700-49_Data_Aire_DAP Page 43 of 48
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll_Free: 888-509-1970 email: [email protected]
Byte Bit
Relative
Offset
Location in
Data Array
(Absolute
Offset) Each
alarm stored as
a separate bit
Location in Data
Array (Absolute
Offset) Each set
of 8 alarms
stored as a
byte*
046, 048 and 049 Units DAP 80 Units
3 0 24 97 46:00
Low air temperature
warning Local alarm #1: See
tag inside door
3 1 25 98 46:01
High air temperature
warning Local alarm #2: See
tag inside door
3 2 26 99 46:02 Low Humidity warning
Local alarm #3: See
tag inside door
3 3 27 100 46:03 High Humidity warning
Local alarm #4: See
tag inside door
3 4 28 101 46:04 Low chilled-water-in alarm
Standby pump on:
check primary pump
3 5 29 102 46:05
High chilled-water-in
alarm
UPS power on:
check main power
supply
3 6 30 103 46:06
Low chilled-water-out
alarm Custom message on
optional input #1
3 7 31 104 46:07
High chilled-water-out
alarm Custom message on
optional input #2
4 0 32 105 47:00
High or Low limits
misadjusted Custom message on
optional input #3
4 1 33 106 47:01
Air temperature sensor
error Custom message on
optional input #4
4 2 34 107 47:02 Humidity sensor error
Humidification
Inhibited
4 3 35 108 47:03 Discharge air sensor error Reheat inhibited
4 4 36 109 47:04
No communications with
temp/humid module
Reheat and
humidification
inhibited
4 5 37 110 47:05
No communications with
LCD module
Discharge air
temperature limit
(just a condition)
4 6 38 111 47:06
Alarm network
communications failure
Reheat mode during
dehumidification
(just a condition)
4 7 39 112 47:07
AC Power or controller
restart
Manual Override:
Check bypass
switches (DAPII ver
5.1 and later)
5 0 40 113 48:00
Network doppelganger
error
N/A
5 1 41 114 48:01
Incompatible Fahrenheit /
centigrade mode
N/A
5 2 42 115 48:02
Schedule normal
maintenance due
N/A
5 3 43 116 48:03
compressor short cycle
warning
N/A
5 4 44 117 48:04
Fan motor overload,
check motor amperage
N/A
