FieldServer Data Aire (DAP) FS-8704-49 - Manual (Page 14)

FS-8700-49_Data_Aire_DAP Page 14 of 48
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll_Free: 888-509-1970 email: [email protected]
Array
Location
Method
Num
Elements
Data Field 2 3 4 5 6 7 8 9 14 15 Message Type
73 3 56
bitErrors - see Appendix
E.4 for more information
x x x x x Dap-Stat
185 1 1 runtime_c1 x x x x x Dap-Xtra
186 1 1 runtime_c2 x x x x x Dap-Xtra
187 1 1 runtime_c3 x x x x x Dap-Xtra
188 1 1 runtime_c4 x x x x x Dap-Xtra
189 1 1 runtime_ht1 x x x x x Dap-Xtra
190 1 1 runtime_ht2 x x x x x Dap-Xtra
191 1 1 runtime_ht3 x x x x x Dap-Xtra
192 1 1 runtime_hum x x x x x Dap-Xtra
193 1 1 runtime_evap x x x x x Dap-Xtra
194 1 1 runtime_cond x x x x x Dap-Xtra
195 1 1 runtime_dehum x x x x x Dap-Xtra
196 1 1 runtime_esc x x x x x Dap-Xtra
197 1 1 runtime_cwc x x x x x Dap-Xtra
198 4 20 errors x x x x x Dap-Xtra
218 6 10 errage x x x x x Dap-Xtra
258 1 1 version x x x x x Dap-Xtra
259 2 1 tmbmair x x x x x Dap-Xtra
260 2 1 tmbhum x x x x x Dap-Xtra
261 1 1 tmbairdb x x x x x Dap-Xtra
262 6 13 runtimes (as array) x x x x x Dap-Xtra
314 3 80 bitErrors x x x x x Dap-Xtra
474 4 1 adj_rate X X X Dap-Menu
478 1 1 alrm_delay_1 X X X Dap-Menu
479 1 1 alrm_delay_2 X X X Dap-Menu
480 1 1 alrm_delay_3 X X X Dap-Menu
481 4 1 alrm_enable_1 X X X Dap-Menu
482 4 1 alrm_enable_2 X X X Dap-Menu
483 4 1 alrm_enable_3 X X X Dap-Menu
484 4 1 alrm_select_1 X X X Dap-Menu
485 4 1 alrm_select_2 X X X Dap-Menu
486 4 1 alrm_select_3 X X X Dap-Menu
487 1 1 chilled_water X X X Dap-Menu
488 1 1 compressor_config X X X Dap-Menu
489 1 1 c_mode X X X Dap-Menu
490 2 1 fire_lim X X X Dap-Menu
491 1 1 heat_strip_config X X X Dap-Menu
492 1 1 hi_cal X X X Dap-Menu
493 1 1 hi_h_cal X X X Dap-Menu
494 2 1 hi_t_lim X X X Dap-Menu
495 1 1 humid_config X X X Dap-Menu
496 1 1 h_calib X X X Dap-Menu
497 1 1 lead_lag X X X Dap-Menu
