FS-8700-49_Data_Aire_DAP Page 19 of 48
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll_Free: 888-509-1970 email: [email protected]
FieldServer
Array
Location
FieldServer Data
Field
Point Description
Message
Type
D/A Control Panel
Type
60 LoHum
Lowest Humidity in the
last 24 hrs
DAP Stat All
61 Chilled_water Water Valve setting DAP Stat All
62 Compressor_config Compressor configuration DAP Stat All
63 heat_strip_config Heating configuration DAP Stat All
64 hum_config Humidifier configuration DAP Stat All
65 csUtilPct
Utilization Percentage of
cooling in the last 24 hrs
DAP Stat All
66 hsUtilPct
Utilization Percentage of
heating in the last 24 hrs
DAP Stat All
67 ValveUtilPct
Utilization Percentage of
CW valve in the last 24
hrs
DAP Stat All
68 humUtilPct
Utilization Percentage of
humidifier in the last 24
hrs
DAP Stat All
69 alrm_select_1
Message for optional
alarm Input #1 selection
DAP Stat All
70 alrm_select_2
Message for optional
alarm Input #2 selection
DAP Stat All
71 alrm_select_3
Message for optional
alarm Input #3 selection
DAP Stat All
72 alrm_select_4
Message for optional
alarm Input #4 selection
DAP Stat All
73 bitErrors Alarm History DAP Stat All
185 runtime_c1 Compressor 1 runtime DAP-Xtra All
186 runtime_c2 Compressor 2 runtime DAP-Xtra All
187 runtime_c3 Compressor 3 runtime DAP-Xtra DAP046 only
188 runtime_c4 Compressor 4 runtime DAP-Xtra DAP046 only
189 runtime_ht1 Heating stage 1 runtime DAP-Xtra All
190 runtime_ht2 Heating stage 2 runtime DAP-Xtra All
191 runtime_ht3 Heating stage 3 runtime DAP-Xtra All
192 runtime_hum Humidification runtime DAP-Xtra All
193 runtime_evap Blower/ Fan runtime DAP-Xtra All
194 runtime_cond Condenser runtime DAP-Xtra All
195 runtime_dehum dehumidification runtime DAP-Xtra All
196 runtime_esc Energy saver runtime DAP-Xtra All
197 runtime_cwc
Chilled water Valve
runtime
DAP-Xtra All
198 errors Alarm History DAP-Xtra All
218 errage Alarm History time (hrs) DAP-Xtra All
258 version
DAP II software revision
number
DAP-Xtra All
259 tmbmair Temperature setpoint DAP-Xtra DAP049,048,046
260 tmbhum Humidity setpoint DAP-Xtra DAP049,048,046
261 tmbairdb Temperature deadband DAP-Xtra DAP049,048,046
262 runtimes runtimes array (in hrs) DAP-Xtra DAP049,048,046
314 bitErrors DAP-Xtra DAP049,048,046
