Appendix A.3. Data Table 3 - Unit Types
When the driver reads everything from a device it must first obtain the device’s unit type so
that it can determine what other data is available. Once the unit type is obtained then the
driver updates the ‘Unit-Type’ field visible on the node screen of the RUIDebug program.
The unit type is also available in the Data Array defined in table 4.4.5.1.
The following table lists the unit types that can be processed by this driver.
Unit Type
Numeric Unit Type
Description
"-"
0
Unknown/unavailable/un-initialized
"1"
1
044 data logger
"2"
2
046 expanded DAP
"3"
3
046 2 mod chiller
"4'
4
046 3 mod chiller
"5"
5
048 DAP, 80-character display
"6"
6
049 DAP, 16-character display
"7"
7
080 DAP II, no relay expansion
"8"
8
080 Chiller II
"9"
9
080 DAP II, with relay expansion
"10"
10
Not Defined
"11"
11
Not Defined
"12"
12
Not Defined
"13"
13
Not Defined
"E"
14
080 DAP II, with analog module
"F"
15
080 DAP II, with relay and analog
