FieldServer Data Aire (DAP) FS-8704-49 - Manual (Page 24)

FS-8700-49_Data_Aire_DAP Page 24 of 48
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll_Free: 888-509-1970 email: [email protected]
Note 1:mode: 2' bit definitions: Note 2: hold: 2' bit definitions:
0X01 Unit is in centigrade mode 0X01 needed cooling is inhibited
0X02 RFU , always 1 0X02 needed heatingg is inhibited
0X04 RFU , always 1 0X04 needed humidification is inhibited
0X08 Unit is dehumidifying 0X08 needed dehumidification is inhibited
0X10 Unit is humidifying 0X10 not used
0X20 Energy save is active 0X20 not used
0X40 not used 0X40 Network"standby" inhibit is active
0X80 not used 0X80 Network"off" inhibit is active
Note 2: errors: 7*2' bit definitions:
00
Manual override:check bypass switches errors[0], bit 0x01
01 water detected under floor errors[0], bit 0x02
02 No air flow, check belt and motor errors[0], bit 0x04
03 dirty filter: check filter errors[0], bit 0x08
04 Humidifier problem: check water pressure errors[0], bit 0x10
05 Low voltage warning errors[0], bit 0x20
06 Firestat alarm, unit shutdown errors[0], bit 0x40
07 compressor short cycle errors[0], bit 0x80
08 power problem or unit restart errors[1], bit 0x01
09 humidity sensor problem errors[1], bit 0x02
10 temperature sensor problem errors[1], bit 0x04
11 schedule maintenance due errors[1], bit 0x08
12 high presure C1: manual reset errors[1], bit 0x10
13 low presure C1: auto reset errors[1], bit 0x20
14 high presure C2: manual reset errors[1], bit 0x40
15 low presure C2: auto reset errors[1], bit 0x80
16 smoke detector: unit shutdown errors[2], bit 0x01
17 No water flow :check pump errors[2], bit 0x02
18 Discharge temperature sensor problem errors[2], bit 0x04
19 High Temperature warning errors[2], bit 0x08
20 Low temperature warning errors[2], bit 0x10
21 High humidity warning errors[2], bit 0x20
22 low humidity warning errors[2], bit 0x40
23 Fan motor overload: check motor amperage errors[2], bit 0x80
24 Local alarm 1: see tag inside door errors[3], bit 0x01
25 Local alarm 2: see tag inside door errors[3], bit 0x02
26 Local alarm 3: see tag inside door errors[3], bit 0x04
27 Local alarm 4: see tag inside door errors[3], bit 0x08
28 Standby Pump on: check primary pump errors[3], bit 0x10
29 UPS power on: check primary power errors[3], bit 0x20
30 Custom message on optional input 1 errors[3], bit 0x40
31 Custom message on optional input 2 errors[3], bit 0x80
32 Custom message on optional input 3 errors[4], bit 0x01
33 Custom message on optional input 4 errors[4], bit 0x02
34 Humidification inhibited errors[4], bit 0x04
35 Reheat inhibited errors[4], bit 0x08
36 Reheat and humidification inhibited errors[4], bit 0x10
37 Discharge air temperature limit errors[4], bit 0x20
38 Reheat mode during dehumidication errors[4], bit 0x40
39 Manual override:check bypass switches errors[4], bit 0x80
40 High condensate water level errors[5], bit 0x01
