Array
Location
Method
Num
Elements
Data Field 2 3 4 5 6 7 8 9 14 15 Message Type
1086 4 1 voice X X X X Dap80-Menu
1100 1 1 sensor_1_name x x Dap80-Analog
1101 1 1 sensor_1_units x x Dap80-Analog
1102 1 1 sensor_1_type x x Dap80-Analog
1103 1 1 sensor_1_min_val x x Dap80-Analog
1104 1 1 sensor_1_max_val x x Dap80-Analog
1105 1 1 sensor_1_cal x x Dap80-Analog
1106 1 1 sensor_2_name x x Dap80-Analog
1107 1 1 sensor_2_units x x Dap80-Analog
1108 1 1 sensor_2_type x x Dap80-Analog
1109 1 1 sensor_2_min_val x x Dap80-Analog
1110 1 1 sensor_2_max_val x x Dap80-Analog
1111 1 1 sensor_2_cal x x Dap80-Analog
1112 1 1 sensor_1_input x x Dap80-Channels
1113 1 1 sensor_2_input x x Dap80-Channels
1114 1 1 sensor_3_input x x Dap80-Channels
Appendix A.2. Data Table 2 - Point Descriptions
FieldServer
Array
Location
FieldServer Data
Field
Point Description
Message
Type
D/A Control Panel
Type
1 Zone Zone ID DAP config All
2 Inhibit
Unit On/ Standby/ Off
Status
DAP config All
3 Unit Type Type Of DAP Panel DAP Unit All
4 temp Current Temperature DAP Stat All
5 hum Current Humidity DAP Stat All
6 d-temp
Current discharge
temperature
DAP Stat All
7 mode
Current Unit mode (see
note 1)
DAP Stat All
23 hold
Current Functions are
inhibited by Network (see
note 2)
DAP Stat All
39 cs_on Cooling stages on DAP Stat All
40 hs_on Heating stage on DAP Stat All
41 valvePCT
Openning Percentage of
Chilled water valve
DAP Stat All
42 hVlvPCT
Openning Percentage of
hot water valve
DAP Stat All
43 errors Alarm (see note 3) DAP Stat All
57 hiTemp
Highest Temperature in
the last 24 hrs
DAP Stat All
58 loTemp
Lowest Temperature in
the last 24 hrs
DAP Stat All
59 hiHum
Highest Humidity in the
last 24 hrs
DAP Stat All
