FS-8700-49_Data_Aire_DAP Page 23 of 48
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll_Free: 888-509-1970 email: [email protected]
FieldServer
Array
Location
FieldServer Data
Field
Point Description
Message
Type
D/A Control Panel
Type
1085 Valve_config
Chilled water Valve
configuration
DAP80 Menu DAP80
1086 voice Audible alarm tone setting DAP80 Menu DAP80
1100 sensor_1_name
Optional Analog sensor 1
name
DAP80 Menu DAP80 W/analog
1101 sensor_1_units
Optional Analog sensor 1
units
DAP80 Menu DAP80 W/analog
1102 sensor_1_type
Optional Analog sensor 1
Type
DAP80 Menu DAP80 W/analog
1103 sensor_1_min_val
Optional Analog sensor 1
minimum value
DAP80 Menu DAP80 W/analog
1104 sensor_1_max_val
Optional Analog sensor 1
maximum value
DAP80 Menu DAP80 W/analog
1105 sensor_1_cal
Optional Analog sensor 1
calibration offset
DAP80 Menu DAP80 W/analog
1106 sensor_2_name
Optional Analog sensor 2
name
DAP80 Menu DAP80 W/analog
1107 sensor_2_units
Optional Analog sensor 2
units
DAP80 Menu DAP80 W/analog
1108 sensor_2_type
Optional Analog sensor 2
Type
DAP80 Menu DAP80 W/analog
1109 sensor_2_min_val
Optional Analog sensor 2
minimum value
DAP80 Menu DAP80 W/analog
1110 sensor_2_max_val
Optional Analog sensor 2
maximum value
DAP80 Menu DAP80 W/analog
1111 sensor_2_cal
Optional Analog sensor 2
calibration offset
DAP80 Menu DAP80 W/analog
1112 sensor_1_input sensor 1 input DAP80 Menu DAP80 W/analog
1113 sensor_2_input sensor 2 input DAP80 Menu DAP80 W/analog
1114 sensor_3_input sensor 3 input DAP80 Menu DAP80 W/analog
